Boart Longyear 44 Rig Details

Boart Longyear 44 Boart Longyear 44 Boart Longyear 44

Rig Description

The Boart Longyear 44 surface core drilling rig is a flexible solution for any kind of terrain. Mounted optionally on truck or on skids can be installed easily in open landscapes or even on mine benches.

  • Wireline
  • Down-the-hole
  • Truck, skid
  • HQ, HQ3, NQ, NQ

Boart Longyear 44 Rig Details Specs

  • DEUTZ 914 / 74kW (99hp) RPM : 2800 Diesel turbocharged Cooling : water Holding force : 100kN Pull force : 75kN Hydraulic chuck Boyles : 12HH Mud pump : Piston pump 110lt/40bar Drilling Capacity : 1100m (ΝQ) Drilling angle : 55 o -90 o
  • RPM : 2800
  • Diesel turbocharged Cooling : water Holding force : 100kN Pull force : 75kN Hydraulic chuck Boyles : 12HH Mud pump : Piston pump 110lt/40bar Drilling Capacity : 1100m (ΝQ) Drilling angle : 55 o -90 o
  • Cooling : water
  • Holding force : 100kN
  • Pull force : 75kN
  • Hydraulic chuck Boyles : 12HH
  • Mud pump : Piston pump 110lt/40bar
  • Drilling Capacity : 1100m (ΝQ)
  • Drilling angle : 55 o -90 o
